  Ubiquiti Multi Mode (LC) SFP Module Pair

  Ubiquiti Multi Mode (LC) SFP Module
  Pair

  The UF-MM1G is ideal for short-distance, outdoor, bi-directional,
  multi-mode fiber runs for distances of up to 550m at 1 Gbps.

  Outdoor Fiber Installations

  For short-distance runs of 300+ meters, use UFiber 1G multi-mode modules
  for maximum reuse of existing infrastructure.

  UF-MM-1G-S

  Supported Media Multi-Mode Fiber
  Connector Type (1) LC
  BiDi ✓
  TX Wavelength
  850 nm

  RX Wavelength
  850 nm

  Data Rate 1.25 Gbps SFP
  Cable Distance 550 m
  Pack Options 1-Pair

  Please note: This kit is only sold as a pair (one box with 2 units inside)

  Read more

  Quick View
•

  Ubiquiti UISP LTU XR – Long-range, 29 dBi antenna

  5 GHz LTU® client that establishes
  extremely long-distance wireless links with an LTU Rocket serving as its base
  station.

  The LTU XR is a high-performance, cost-effective PtMP CPE for wireless ISPs
  that can reach up to a 550 Mbps throughput rate. The LTU XR also facilitates
  independent transmission and receives channel frequency configurations
  anywhere within its radio band to avoid local interference and ensure
  superior client performance. Additionally, the LTU XR is equipped with a Bluetooth
  management radio so it’s easy to set up and configure with the UISP® Mobile
  app.

  Features:

  Proprietary Ubiquiti LTU core processor
  Long-range, 29 dBi antenna with InnerFeed® technology
  High data and performance rate (1024 QAM)
  Link range up to 35 km
  Channel width flexibility (10/20/30/40/50 MHz bandwidth)
  Central configuration management from the AP side
  Frequency splitting
  Router mode support
  Integrated GPS
  Link planning support via ISP Design Center
  Quick, Bluetooth-powered setup with the UISP Mobile app

  Read more

  Quick View
•

  Ubiquiti LTU LR – Long Range 5.8GHz 26dBi LTU CPE

  5 GHz PtMP LTU Long-Range Client,
  functions in a PtMP environment with the LTU-Rocket as the BaseStation.

  Incorporating innovative industrial design with advanced technology, the
  LTU LR is a Point-to-MultiPoint (PtMP) 5 GHz Radio with an integrated antenna
  designed for use as a PtMP CPE. LTU technology that breaks through the
  limitations of 802.11 Wi-Fi technology and supports 1024QAM for high
  performance and flexible bandwidth (10/20/30/40/50 MHz).

  Features:

  PtMP CPE
  1024 QAM
  10/20/30/40/50 MHz channel bandwidth
  Central configuration management from AP side
  Frequency split
  Auto power adjustments
  Router mode support
  Range up to 30km

  Functions in a PtMP environment with the LTU-Rocket as the basestation

  Read more

  Quick View
•

  Ubiquiti LTU Lite GHz 13dBi CPE

  5 GHz PtMP LTU Client, functions in a
  PtMP environment with the LTU-Rocket as the BaseStation.

  Incorporating Ubiquiti’s proprietary LTU technology, the LTU-Lite is a 5
  GHz radio with an integrated antenna design for use as a PtMP CPE. LTU technology
  breaks through the limitations of 802.11 Wi-Fi technology and supports 1024
  QAM for superior performance. Channel width flexibility (10/20/30/40/50 MHz)
  allows independent TX and RX channel frequency configurations anywhere within
  the radio band to avoid local interference.

  Features

  PtMP CPE
  1024 QAM
  10/20/30/40/50 MHz channel bandwidth
  Central configuration management from AP side
  Frequency split
  Auto power adjustments
  Router mode support

  Functions in a PtMP environment with the LTU-Rocket as the basestation

  Read more

  Quick View
•

  Ubiquiti LTU Rocket

  Ubiquiti LTU Rocket

  Ubiquiti introduces the LTU Rocket®, the first Point-to-Multi-Point (PtMP)
  BaseStation radio in the LTU™ product family. Operating in the 5 GHz
  frequency band, the LTU Rocket is a spectrally efficient, noise-resilient
  PtMP AP specifically designed for wireless ISPs (WISPs).

  Primary features of the LTU Rocket include:

  600+ Mbps PtMP performance1
  Up to 64 client connections per AP2
  2+ Million pps
  Proprietary RF filtering

  1 1+ Gbps with future firmware upgrade.

  2 255 client connections with future firmware upgrade

  Superior Performance

  LTU is a new, proprietary technology with custom silicon and radio design
  that break through the limitations of 802.11 Wi-Fi technology. This enables
  LTU to deliver far superior performance over previous airMAX products that
  are based on 802.11 Wi-Fi.The LTU Rocket is designed for WISPs from the
  ground floor up. Its core communications processing engine enables low
  latency, long-range capability, DFS flexibility, higher constellations,
  better power output, and improved receive sensitivity.

  Seamless Compatibility

  The LTU Rocket is designed to be paired with a variety of Ubiquiti antennas
  to suit the needs of each installation. The radio includes a mounting bracket
  that allows it to be used with a 5 GHz airMAX® Sector antenna or airMAX Omni
  antenna for a complete 5 GHz PtMP BaseStation. You can even pair three LTU
  Rocket radios with the airPrism® 5 GHz 3×30° HD Sector Antenna for
  co-location deployments. The LTU Rocket also works with any CPE device in the
  LTU family, such as the LTU-Pro.

  Deployment Example:

  Channel Width Flexibility

  Channel width flexibility allows independent TX and RX channel frequency
  configurations anywhere within the radio band to avoid local interference.
  Channel width options include:

  10 MHz
  20 MHz
  30 MHz
  40 MHz
  50 MHz
  Up to 100 MHz*

  * Available with future firmware upgrade

  Auto Power Adjustments

  By default, the Auto Output Power* option allows the LTU Rocket to set the
  output power (EIRP) to the appropriate level.

  Frequency Split

  The LTU Rocket can use different frequencies for TX and RX to avoid
  interference.

  Signal Control

  The LTU Rocket’s target TX output power controls each station’s TX output
  power. A PtMP network can manage signal levels to enhance network stability
  and achieve optimal wireless performance with the highest possible
  modulation.

  Convenient Configuration

  To manage the LTU Rocket, you have two options: the LTU Configuration
  Interface and Ubiquiti Network Management System (UNMS™). Either option lets
  you manually configure the LTU Rocket. The LTU Rocket can also be used to
  automatically configure the stations. On each station, use the Find My AP
  feature to scan for APs using the same channel bandwidth, select the
  appropriate LTU Rocket, and then use it to configure the station.

  Integrated GPS

  Built-in GPS improves synchronization and allows map and Fresnel views on
  the Dashboard.

  LTU Configuration Interface

  PtMP Dashboard

  The Dashboard offers map and Fresnel views* so you can visualize the
  network. The map view shows your PtMP links overlaid on a geographic map,
  while the Fresnel view shows the link calculated for your selected CPE,
  including line of sight, first Fresnel zone, and 60% clearance zone.
  * Available for models equipped with GPS.

  New graphs provide instant status updates and help you to detect
  connectivity issues and their effects on PtMP performance:
  The airtime distribution bar graph displays in real time how much airtime
  each CPE is using. Click any point to view the airtime and link score for a
  specific CPE.

  The AP RF environment bar graph shows ambient RF noise levels across the
  frequency spectrum.
  The combined remote RF environment bar graph also shows ambient RF noise
  levels but for the combined environment of all of the remote CPEs.

  The local and remote RX rate histograms show the receive modulation rates
  of the various CPEs.

  Real-Time Spectral Analysis
  airView® spectral analysis runs on a dedicated and independent receiver,
  which has excellent EVM (Error Vector Magnitude) performance.
  The receiver can also perform other tasks, such as a search for channel
  occupancy, DFS detection, and automatic channel/frequency assignment.
  Calibration (signal level measurement accuracy) and resolution bandwidth
  options are enhanced. Spectral zoom (user-defined scan limits) is also
  available.

  Read more
