The SXTsq Lite5 is a compact and
lightweight outdoor wireless device with an integrated antenna. Perfect for
point to point links of up to 12 kilometers or as a CPE unit. It is compact,
weatherproof and easy to mount. The SXTsq Lite5 retains a 16dBi antenna like
the SXT Lite5, our previous model, yet the antenna design has been improved
and the physical size has been dramatically reduced – the SXTsq is two times
thinner (see photos for comparison).

The device can be mounted on horizontal and vertical poles and masts, but
for precise alignment, separately available is the QuickMount Pro, which
allows to adjust in every angle (see photo and related product).

– SXTsq Lite5-US (USA) is factory locked for 5170-5250MHz and 5725-5835MHz
frequencies. This lock can not be removed.

– SXTsq Lite5 (International) supports 5150MHz-5875MHz range (Specific
frequency range can be limited by country regulations).

  Send purchase questions
 Specifications
 Support & Downloads
 Gallery
 Test results
Specifications
Details
Product code RBSXTsq5nD
Architecture MIPSBE
CPU AR9344
CPU core count 1
CPU nominal frequency 600 MHz
Dimensions 129x129x34mm
RouterOS license 3
Operating System RouterOS
Size of RAM 64 MB
Storage size 16 MB
Storage type FLASH
MTBF Approximately 100’000 hours at 25C
Tested ambient temperature -40°C to 70°C
Suggested price $46.00
Powering
Details
Number of DC inputs 1 (PoE-IN)
Max power consumption 6 W
Cooling type Passive
PoE in Passive PoE
PoE in input Voltage 10-30 V
Wireless specifications
Details
Wireless 5 GHz Max data rate 300 Mbit/s
Wireless 5 GHz number of chains 2
Wireless 5 GHz standards 802.11a/n
Antenna gain dBi for 5 GHz 16
Wireless 5 GHz chip model AR9344
Wireless 5 GHz generation Wi-Fi 4
Ethernet
Details
10/100 Ethernet ports 1
Certification & Approvals
Details
Certification CE, FCC, IC, EAC, ROHS
IP IP54
Wireless specifications
5 GHz Transmit (dBm) Receive Sensitivity
6MBit/s 25 -96
54MBit/s 20 -80
MCS0 25 -96
MCS7 19 -75
Included parts

24V 0.38A power adapter

Metal ring (one)

PoE injector

The device has an operating system preinstalled and licensed. No separate
purchase is necessary and the product is ready to use. The device includes
free software updates for the life of the product or a minimum of 5 years
starting from date of purchase..
