MikroTik hEX S Kenya | +254100720022
5x Gigabit Ethernet, SFP, Dual Core
880MHz CPU, 256MB RAM, USB, microSD, RouterOS L4, IPsec hardware encryption
support and The Dude server package
…………….
MikroTik provides hardware and software for Internet connectivity in most of the countries around the world. Our experience in using industry standard PC hardware and complete routing systems
ORDER NOW!! +254100720022 / +254720548999
hEX S is a five port Gigabit Ethernet
router for locations where wireless connectivity is not required. Compared to
the hEX, the hEX S also features an SFP port and PoE output on the last
port.
It is affordable, small and easy to use, but at the same time comes with a
very powerful dual core 880 MHz CPU and 256 MB RAM, capable of all the
advanced configurations that RouterOS supports. The device has a USB 2.0, PoE
output for Ethernet port #5 and a 1.25Gbit/s SFP cage. The port #5 can power
other passive PoE capable devices with the same voltage as applied to the
unit
IPsec hardware encryption (~470 Mbps) and The Dude server package is
supported, microSD slot on it provides improved r/w speed for file storage
and Dude.
Send purchase questions
Specifications
Support & Downloads
Gallery
Test results
Specifications
Details
Product code RB760iGS
Architecture MMIPS
CPU MT7621A
CPU core count 2
CPU nominal frequency 880 MHz
CPU Threads count 4
Switch chip model MT7621A
Dimensions 113 x 89 x 28 mm
RouterOS license 4
Operating System RouterOS
Size of RAM 256 MB
Storage size 16 MB
Storage type FLASH
MTBF Approximately 100’000 hours at 25C
Tested ambient temperature -40°C to 70°C
IPsec hardware acceleration Yes
Suggested price $79.00
Powering
Details
Number of DC inputs 2 (DC jack, PoE-IN)
DC jack input Voltage 12-57 V
Max power consumption 24 W
Max power consumption without attachments 6 W
Cooling type Passive
PoE in 802.3af/at
PoE in input Voltage 12-57 V
PoE-out
Details
PoE-out ports Ether5
PoE out Passive PoE up to 57V
Max out per port output (input 18-30 V) 500 mA
Max out per port output (input 30-57 V) 500 mA
Max total out (A) 500 mA
Ethernet
Details
10/100/1000 Ethernet ports 5
Fiber
Details
SFP ports 1
Peripherals
Details
Memory card type microSD
Memory Cards 1
Number of USB ports 1
USB Power Reset Yes
USB slot type USB type A
Max USB current (A) 1
Other
Details
PCB temperature monitor Yes
Voltage Monitor Yes
Mode button Yes
Beeper Yes
Certification & Approvals
Details
Certification CE, EAC, ROHS
IP IP20
Included parts
24V 1.2A power adapter
The device has an operating system preinstalled and licensed. No separate
purchase is necessary and the product is ready to use. The device includes
free software updates for the life of the product or a minimum of 5 years
starting from date of purchase..
