MikroTik  Chateau LTE6 ax Kenya | +254100720022

Are you tired of those suspicious,
low-quality default routers from your service providers? So many households
are switching to mobile internet, but those default routers can really ruin
the experience. Not only do they lack features, speed, and power, the designs
can get weird with all the black boxes and spiky antennas. That’s why we
decided to take everything we’ve learned over the last 20 years of networking
excellence and create a single device that will make most households happy:
the – MikroTik Chateau. It features a purposeful balance of extensive features,
accessible pricing, and classy design that will fit right in

Chateau is a high-speed, dual-band home access point that adapts to your
needs. It features a powerful quad- core ARM CPU, a fast, reliable, and
responsive CAT6 LTE modem for excellent mobile connectivity, and the most
advanced networking software on the market – RouterOS. But don’t worry – it
can be as simple or as complex as you want. Chateau is designed to serve the
most diverse user groups: IT professionals can push it to its limits, regular
households can plug it in and forget it exists. With Chateau, you will always
have options.

Compared to the regular Chateau LTE6, this version features a supercharged
quad-core ARM CPU running at 1.8 GHz. It can handle even the most complex
tasks without breaking a sweat. You can run complex firewall rules, provide
encrypted VPN tunnels for an entire office, run the most demanding container
apps right on your router, and more! The addition of 2.5 Gigabit Ethernet
gives you even more options. You can use the ultra- fast port to connect
extra devices – like a home media server – or use it as your primary ISP
connection while keeping the LTE modem for backup.

Remove the bottleneck in your mobile setup

Do you dream of escaping the hustle and bustle of the city and moving to
the countryside? Perhaps you’ve already made the move but are frustrated by
the slow internet speeds. Fear not, because Chateau is here to solve all your
connectivity problems.

Many rural households are limited by cheap, featureless LTE routers that
simply can’t handle the demands of modern internet usage. That’s where
Chateau comes in. When the leading mobile operator in Latvia – LMT – replaced
their previous client routers with Chateau devices, customer satisfaction
went through the roof! Same LTE towers, same data plans, and a brand new
Chateau – just like that! What is the point of having brand new phones,
excellent LTE coverage, high-end laptops, and so on… if your old router is
the bottleneck?

That’s right – wireless signal is now stronger than ever. Due to the Gen 6
802.11ax standard, we’ve seen up to 40% higher speed in the 5 GHz spectrum
and up to 90% higher speed in the 2.4 GHz spectrum.

The freedom of LTE

Reach consistent speeds of up to 300 Mbps with carrier aggregation, as CAT6
allows devices to use multiple bands simultaneously. That is a huge advantage
in areas with many LTE users. Chateau LTE6 provides better responsiveness in
a crowded environment and higher efficiency for weaker signal situations in
the countryside. Depending on the service provider, we have seen Internet
speed doubling in rural areas after switching to carrier aggregation, so
there is no need to wait for cable network expansions.

Perfect for all walks of life

Chateau comes with all the advanced RouterOS features, so you’re getting
enterprise-level solutions with consumer-grade pricing. Run a secure VPN from
the office directly to your home, enable all kinds of parental control, dive
deep into specific firewall rules and IPsec hardware acceleration, configure
VLANs, set up e-mail or SMS notifications… You can even automate complex
trigger notifications. For example: “WARNING, WARNING! Your bandwidth has
reached X amount for Y duration!” If you can imagine it – RouterOS can
achieve it. However, if you don’t need all the complex stuff – Chateau can
still be your best friend. In fact, this is the best choice for mobile
operators that don’t want their clients to do any configuration. Chateau
supports the TR-069 technology that allows creating custom remote client
management options. You can have the most straightforward and basic router
settings on the same web-page that you are using to pay the mobile bill. And
we offer different label or printed branding options on volume orders.
Furthermore, we can offer special project pricing and additional discounts
for mobile operators to bring the costs down even more!

You don’t have to wait for cable network expansion to have fast and steady
Internet at home. Mobile networks are great. If you’re using a Chateau.

  Send purchase questions
 Specifications
 Support & Downloads
 Gallery
 Test results
Specifications
Details
Product code S53UG+5HaxD2HaxD-TC&FG621-EA
Architecture ARM 64bit
CPU IPQ-6010
CPU core count 4
CPU nominal frequency auto MHz
Switch chip model IPQ-6010
RouterOS license 4
Operating System RouterOS v7
Size of RAM 1 GB
Storage size 128 MB
Storage type NAND
MTBF Approximately 200’000 hours at 25C
Tested ambient temperature -40°C to 70°C
IPsec hardware acceleration Yes
Suggested price $199.00
Wireless capabilities
Details
Wireless 2.4 GHz Max data rate 574 Mbit/s
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n/ax
Antenna gain dBi for 2.4 GHz 2
Wireless 2.4 GHz chip model QCN-5022
Wireless 2.4 GHz generation Wi-Fi 6
Wireless 5 GHz Max data rate 1200 Mbit/s
Wireless 5 GHz number of chains 2
Wireless 5 GHz standards 802.11a/n/ac/ax
Antenna gain dBi for 5 GHz 4
Wireless 5 GHz chip model QCN-5052
Wireless 5 GHz generation Wi-Fi 6
WiFi speed AX1800
Mobile
Details
3G Category R8 (42.2Mbps Downlink, 11.2Mbps Uplink)
3G bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)
LTE Category 6 (300Mbit/s Downlink, 50Mbit/s Uplink)
MIMO DL 2×2
MIMO UL 1×1
LTE FDD bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900
MHz) / 20 (800MHz) / 28 (700MHz)
LTE TDD bands 38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz)
TAC 86335904
Ethernet
Details
10/100/1000 Ethernet ports 4
Number of 2.5G Ethernet ports 1
Peripherals
Details
Number of SIM slots 1 Modem (Micro SIM)
Number of USB ports 1
USB Power Reset Yes
USB slot type USB type A
Max USB current (A) 1
Powering
Details
Number of DC inputs 1 (DC jack)
DC jack input Voltage 12-28 V
Max power consumption 17 W
Max power consumption without attachments 13 W
Cooling type Passive
Certification & Approvals
Details
Certification CE, EAC, ROHS
IP 20
Other
Details
PCB temperature monitor Yes
Voltage Monitor Yes
Mode button Yes
Wireless specifications
2.4 GHz Transmit (dBm) Receive Sensitivity
1MBit/s -100
11MBit/s -94
6MBit/s 24 -96
54MBit/s 21 -80
MCS0 24 -96
MCS7 20 -75
MCS9 19 -70
MCS11 17 -67
5 GHz Transmit (dBm) Receive Sensitivity
6MBit/s 24 -96
54MBit/s 21 -80
MCS0 24 -96
MCS7 20 -75
MCS9 19 -70
MCS11 17 -67
Included parts

24V 1.2A power adapter

UTP Flat Cable (1.5m)

The device has an operating system preinstalled and licensed. No separate
purchase is necessary and the product is ready to use. The device includes
free software updates for the life of the product or a minimum of 5 years
starting from date of purchase..-
……………………………………………………………………
