MikroTik  ATL LTE18 kit Kenya | +254100720022

The world keeps changing, but one thing
remains certain: you’ve got to stay connected. Immediate access to
information is vital. That’s why we’ve developed the ATL: an advanced
technology level directional LTE solution for those who want to squeeze the most
out of LTE base stations. ATL features a phenomenal Category 18 LTE modem and
a Gigabit Ethernet port with PoE-in. Combined with the modern ARM CPU, this
means speeds up to 1 Gbps, no bottlenecks!

One of the key features is the 4×4 MIMO or multiple-input, multiple-output
support. More antennas to work with – higher speed and better signal! You can
expect fantastic performance in the cities with modern base stations. But ATL
can also do wonders in rural areas as it supports a wider frequency band
range for lower band antennas.

There are 4 high-gain middle band (1.7 – 2.7 GHz) and 2 high-gain low band
antennas (700 MHz – 1 GHz, LTE Band 28). Why is that important? Two reasons.
First of all, the 700 and 800 MHz LTE band is one of the most popular
frequency options in the world. It is used by countless mobile operators
everywhere, so ATL will always be able to find some signal. And the second
reason is the nature of the lower frequency itself: this type of radio wave
can travel very far. It all depends on many factors, including how flat the
terrain is, but rest assured – with ATL you are in good hands.

At first glance, the ATL LTE18 kit looks like a spaceship, but there’s a
good reason for that. This design prevents snow and water from collecting and
freezing up. So not only is it compact and easy to ship, it can also handle
some of the roughest weather conditions. ATL is an excellent tool for fast
and stable connections in cold, snowy cities without having to clean the
antenna all the time. And the LTE Category 18 modem is pretty future-proof,
so you won’t have to worry about upgrades for quite some time.

  Send purchase questions
 Specifications
 Support & Downloads
 Gallery
 Test results
Specifications
Details
Product code ATLGM&EG18-EA
Architecture ARM 64bit
CPU 88F3720
CPU core count 2
CPU nominal frequency 800 MHz
RouterOS license 3
Operating System RouterOS v7
Size of RAM 256 MB
Storage size 16 MB
Storage type FLASH
MTBF Approximately 200’000 hours at 25C
Tested ambient temperature -40°C to 70°C
Suggested price $279.00
Powering
Details
Number of DC inputs 1 (PoE-IN)
Max power consumption 8 W
Max power consumption without attachments 8 W
Cooling type Passive
PoE in 802.3af/at
PoE in input Voltage 12-57 V
Mobile
Details
3G Category R8 (42.2Mbps Downlink, 11.2Mbps Uplink)
3G bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)
LTE Category 18 (1.2Gbps Downlink, 150Mbps Uplink)
LTE FDD bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900 MHz) / 20
(800MHz) / 28 (700MHz) / 7 (2600MHz)
LTE TDD bands 38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz)
TAC 86981604
Ethernet
Details
10/100/1000 Ethernet ports 1
Peripherals
Details
Number of SIM slots 1 Modem (Micro SIM)
Number of M.2 slots 1
Other
Details
Mode button Yes
Certification & Approvals
Details
Certification CE, EAC, ROHS
IP 54
Included parts

24V 0.8A power adapter

Gigabit PoE injector

Hose clamp 2

The device has an operating system preinstalled and licensed. No separate
purchase is necessary and the product is ready to use. The device includes
free software updates for the life of the product or a minimum of 5 years
starting from date of purchase..
