MikroTik  SXT SA5 ac Kenya | +254100720022

The new AC standard is here, with up to
866Mbit over the air datarate, 256-QAM modulation, and 80MHz channels.
802.11a/n/ac opens up new possibilities and speeds never possible
before.

The SXT ac is a new member in our 802.11ac product lineup, currently two
models are available — with regular 28 degree antenna, and the SA model with
a 90 wide beam – width sector antenna. Also support 802.11a/n standard,
Nstreme and Nv2 protocols and are compatible with all legacy RouterBOARD
devices.
 Both devices come with Gigabit Ethernet.

New products are backwards compatible – for example, you can replace your
5GHz 802.11a/n legacy Access Point with new 802.11ac product and your
existing customers will still be able to connect to it.

SXT install guide:

– RBSXTG-5HPacD-SAr2-US (USA) is factory locked for 5170-5250MHz and
5725-5835MHz frequencies. This lock can not be removed.

– RBSXTG-5HPacD-SAr2 (International) supports 5150MHz-5875MHz range
(Specific frequency range can be limited by country regulations).

  Send purchase questions
 Specifications
 Support & Downloads
 Gallery
 Test results
Specifications
Details
Product code RBSXTG-5HPacD-SA
Architecture MIPSBE
CPU QCA9557
CPU core count 1
CPU nominal frequency 720 MHz
RouterOS license 4
Operating System RouterOS
Size of RAM 128 MB
Storage size 128 MB
Storage type NAND
MTBF Approximately 200’000 hours at 25C
Tested ambient temperature -40°C to 70°C
Suggested price $119.00
Powering
Details
Number of DC inputs 1 (PoE-IN)
Supported Voltage 15-60V
Max power consumption 12 W
Cooling type Passive
PoE in 802.3af/at
PoE in input Voltage 12-57 V
Wireless specifications
Details
Wireless 5 GHz Max data rate 867 Mbit/s
Wireless 5 GHz number of chains 2
Wireless 5 GHz standards 802.11a/n/ac
Antenna gain dBi for 5 GHz 14
Wireless 5 GHz chip model QCA9892
Wireless 5 GHz generation Wi-Fi 5
Ethernet
Details
10/100/1000 Ethernet ports 1
Peripherals
Details
Number of USB ports 1
USB Power Reset Yes
USB slot type USB type A
Max USB current (A) 1
Other
Details
PCB temperature monitor Yes
Voltage Monitor Yes
Beeper Yes
Certification & Approvals
Details
Certification CE, FCC, IC, EAC, ROHS
IP IP54
Wireless specifications
5 GHz Transmit (dBm) Receive Sensitivity
6MBit/s 31 -96
54MBit/s 28 -81
MCS0 30 -96
MCS7 27 -77
MCS9 22 -72
Included parts

24V 0.8A power adapter

Metal ring (one)

Pole mounting bracket

Gigabit PoE injector

The device has an operating system preinstalled and licensed. No separate
purchase is necessary and the product is ready to use. The device includes
free software updates for the life of the product or a minimum of 5 years
starting from date of purchase..
