MikroTik  mANTBox 52 15s Kenya | +254100720022

Are you managing an outdoor wireless
network with a variety of access points and CPE devices? Then our brand new
mANTBox 52 15s has got you covered – offering powerful built-in antennas,
fascinating connectivity options and more!

Creating an efficient point-to-multipoint connection used to be tricky, but
not anymore: mANTBox 52 15s works well in any setup. The dual-band wireless
capability allows you to use both 2.4 GHz and 5 GHz devices at the same time.
There is a Gigabit Ethernet port and an SFP port for fiber connections.

We have doubled the RAM and added a new quad-core CPU that can handle even
the heaviest loads. mANTBox 52 15s can even provide IPsec hardware offloading
without trouble. Depending on the rest of your setup, you can reach distance
up to 20 km with the built-in dual polarization antenna.

  Send purchase questions
 Specifications
 Support & Downloads
 Gallery
 Test results
Specifications
Details
Product code RBD22UGS-5HPacD2HnD-15S
Architecture ARM 32bit
CPU IPQ-4019
CPU core count 4
CPU nominal frequency auto MHz
Switch chip model IPQ-4019
Dimensions 140 x 348 x 82 mm
RouterOS license 4
Operating System RouterOS
Size of RAM 256 MB
Storage size 16 MB
Storage type FLASH
MTBF Approximately 200’000 hours at 25C
Tested ambient temperature -40°C to +70°C
IPsec hardware acceleration Yes
Suggested price $179.00
Powering
Details
Number of DC inputs 2 (DC jack, PoE-IN)
DC jack input Voltage 12-57 V
Cooling type Passive
PoE in 802.3af/at
PoE in input Voltage 12-57 V
Wireless specifications
Details
Wireless 2.4 GHz Max data rate 300 Mbit/s
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n
Antenna gain dBi for 2.4 GHz 12
Wireless 2.4 GHz chip model IPQ-4019
Wireless 2.4 GHz generation Wi-Fi 4
Wireless 5 GHz Max data rate 867 Mbit/s
Wireless 5 GHz number of chains 2
Wireless 5 GHz standards 802.11a/n/ac
Antenna gain dBi for 5 GHz 15
Wireless 5 GHz chip model IPQ-4019
Wireless 5 GHz generation Wi-Fi 5
Ethernet
Details
10/100/1000 Ethernet ports 1
Fiber
Details
SFP ports 1
Peripherals
Details
Number of USB ports 1
USB Power Reset Yes
USB slot type USB type A
Max USB current (A) 1
Other
Details
PCB temperature monitor Yes
Voltage Monitor Yes
Certification & Approvals
Details
Certification CE, FCC, IC, EAC, ROHS
IP IP55
Wireless specifications
2.4 GHz Transmit (dBm) Receive Sensitivity
1MBit/s 30 -100
11MBit/s 30 -94
6MBit/s 30 -96
54MBit/s 27 -80
MCS0 30 -96
MCS7 26 -75
5 GHz Transmit (dBm) Receive Sensitivity
6MBit/s 30 -96
54MBit/s 27 -80
MCS0 30 -96
MCS7 26 -75
MCS9 23 -72
Included parts

K-41 fastening set

Hose clamp 1

QMP

48 V 0.95 A power adapter

Gigabit PoE injector

The device has an operating system preinstalled and licensed. No separate
purchase is necessary and the product is ready to use. The device includes
free software updates for the life of the product or a minimum of 5 years
starting from date of purchase..
