MikroTik  hAP ac lite TC Kenya | +254100720022

The hAP ac lite is a Dual-concurrent
Access Point, that provides WiFi coverage for 2.4GHz and 5GHz frequencies at
the same time.

Unit is equipped with a 650MHz CPU, 64MB RAM, five 10/100Mbps Ethernet
ports (PoE output on port #5), dual-chain 802.11b/g/n 2.4GHz wireless, single
chain 802.11a/n/ac 5GHz wireless, USB port for 3G/4G modem and a RouterOS L4
license.

New design universal case allows unit to be positioned either horizontally
(desktop) or vertically (tower case). Wall anchored mounting kit is
provided.

We have two versions available – RB952Ui-5ac2nD-TC (International) and
RB952Ui-5ac2nD-TC-US (USA). RB952Ui-5ac2nD-TC-US (USA) is factory locked for
2412-2462MHz, 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be
removed. RB952Ui-5ac2nD-TC (International) supports 2412-2484MHz and 5150MHz
– 5875MHz range (Specific frequency range can be limited by country
regulations).

  Send purchase questions
 Specifications
 Support & Downloads
 Gallery
 Test results
Specifications
Details
Product code RB952Ui-5ac2nD-TC
Architecture MIPSBE
CPU QCA9531
CPU core count 1
CPU nominal frequency 650 MHz
Switch chip model QCA9531
Dimensions 34 x 119 x 98mm
RouterOS license 4
Operating System RouterOS
Size of RAM 64 MB
Storage size 16 MB
Storage type FLASH
MTBF Approximately 100’000 hours at 25C
Tested ambient temperature -30°C to 70°C
Suggested price $59.00
Wireless capabilities
Details
Wireless 2.4 GHz Max data rate 300 Mbit/s
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n
Antenna gain dBi for 2.4 GHz 1.5
Wireless 2.4 GHz chip model QCA9531
Wireless 2.4 GHz generation Wi-Fi 4
Wireless 5 GHz Max data rate 433 Mbit/s
Wireless 5 GHz number of chains 1
Wireless 5 GHz standards 802.11a/n/ac
Antenna gain dBi for 5 GHz 2
Wireless 5 GHz chip model QCA9887
Wireless 5 GHz generation Wi-Fi 5
WiFi speed AC750
Ethernet
Details
10/100 Ethernet ports 5
Peripherals
Details
Number of USB ports 1
USB Power Reset Yes
USB slot type USB type A
Max USB current (A) 1
Powering
Details
Number of DC inputs 2 (PoE-IN, DC jack)
DC jack input Voltage 10-28 V
Max power consumption 20 W
Max power consumption without attachments 8 W
Cooling type Passive
PoE in Passive PoE
PoE in input Voltage 10-28 V
PoE-out
Details
PoE-out ports Ether5
PoE out Passive PoE
Max out per port output (input 18-30 V) 500 mA
Max total out (A) 500 mA
Certification & Approvals
Details
Certification CE, FCC, IC, EAC, ROHS
IP IP20
Wireless specifications
2.4 GHz Transmit (dBm) Receive Sensitivity
1MBit/s 22 -96
11MBit/s 22 -89
6MBit/s 20 -93
54MBit/s 18 -74
MCS0 20 -93
MCS7 16 -71
5 GHz Transmit (dBm) Receive Sensitivity
6MBit/s 23 -93
54MBit/s 20 -75
MCS0 23 -93
MCS7 19 -71
MCS9 16 -63
Included parts

24V 1.2A power adapter

K-47 wall mount set

The device has an operating system preinstalled and licensed. No separate
purchase is necessary and the product is ready to use. The device includes
free software updates for the life of the product or a minimum of 5 years
starting from date of purchase..
