MikroTik  DynaDish 5 Kenya | +254100720022

The DynaDish 5 is a new 802.11ac outdoor
device with an integrated 25dBi antenna. Compact in it’s design, it is a
simple and completely integrated product with everything you need to quickly
install a reliable point to point link.

The DynaDish 5 is powered by a new 720MHz CPU from Qualcomm.

– RBDynaDishG-5HacD-US (USA) is factory locked for 5170-5250MHz and
5725-5835MHz frequencies. This lock can not be removed.

– RBDynaDishG-5HacD (International) supports 5150-5875MHz range (Specific
frequency range can be limited by country regulations).

  Send purchase questions
 Specifications
 Support & Downloads
 Gallery
 Test results
Specifications
Details
Product code RBDynaDishG-5HacDr3
Architecture MIPSBE
CPU QCA9557
CPU core count 1
CPU nominal frequency 720 MHz
Dimensions Ø 404mm, height 175mm (without mount)
RouterOS license 3
Operating System RouterOS
Size of RAM 128 MB
Storage size 16 MB
Storage type FLASH
MTBF Approximately 200’000 hours at 25C
Tested ambient temperature -40°C to 70°C
Suggested price $199.00
Powering
Details
Number of DC inputs 1 (PoE-IN)
Max power consumption 9 W
Cooling type Passive
PoE in 802.3af/at
PoE in input Voltage 11-60 V
Wireless specifications
Details
Wireless 5 GHz Max data rate 867 Mbit/s
Wireless 5 GHz number of chains 2
Wireless 5 GHz standards 802.11a/n/ac
Antenna gain dBi for 5 GHz 25
Wireless 5 GHz chip model QCA9892
Wireless 5 GHz generation Wi-Fi 5
Ethernet
Details
10/100/1000 Ethernet ports 1
Other
Details
PCB temperature monitor Yes
Voltage Monitor Yes
Beeper Yes
Certification & Approvals
Details
Certification CE, FCC, IC, EAC, ROHS
IP IP54
Wireless specifications
5 GHz Transmit (dBm) Receive Sensitivity
6MBit/s 31 -96
54MBit/s 28 -81
MCS0 30 -96
MCS7 27 -77
MCS9 22 -72
Included parts

24V 0.8A power adapter

Gigabit PoE injector

Dynadish mount

U bolt kit

The device has an operating system preinstalled and licensed. No separate
purchase is necessary and the product is ready to use. The device includes
free software updates for the life of the product or a minimum of 5 years
starting from date of purchase..
