Our newest out-of-the-box solution for
LoRa® technology. Works with the 2.4 GHz frequency for LoRa®. Doesn’t
interfere with the 2.4 GHz WLAN signal!
…………….
MikroTik provides hardware and software for Internet connectivity in most of the countries around the world. Our experience in using industry standard PC hardware and complete routing systems
ORDER NOW!! +254100720022 / +254720548999
Our newest out-of-the-box solution for
LoRa® technology. Like the previous wAP LR kits, it contains a pre-installed
UDP packet forwarder to any public or private LoRa® servers and an outdoor
weatherproof wireless access point with 2.4 GHz WLAN interface and Ethernet
port with PoE-in that could be used as a backend.
Here’s the difference: this device works with the 2.4 GHz frequency for
LoRa® as well. That means significantly higher bandwidth, higher data rate,
and less air time. And because of the Chirp modulation technology, it doesn’t
interfere with the 2.4 GHz WLAN signal! A perfect solution for industrial
setups with a high density of sensors.
There is a built-in 2 dBi WLAN / 4.7 dBi LoRa® antenna, but you can add an
external antenna for extra coverage. We suggest using the TOF-2400-8V-4 Omni
antenna for best results.
We’ve decided to keep the classic wAP form-factor that has been tested in
many other MikroTik products – it can deliver excellent and stable
performance in almost any weather conditions. Functional and non-intrusive
design, astonishing durability, and great value remain at the core of this
design.
The whole IoT community is exploring the 2.4 GHz LoRa® possibilities – join
them and be among the first ones to benefit from the increased data
rates.
*) the device has no built in LTE modem, the SIM slot can only be used, if
LoRa interface card is removed and replaced by an LTE modem
Send purchase questions
Specifications
Support & Downloads
Gallery
Specifications
Details
Product code RBwAPR-2nD&R11e-LR2
Architecture MIPSBE
CPU QCA9531
CPU core count 1
CPU nominal frequency 650 MHz
RouterOS license 4
Size of RAM 64 MB
Storage size 16 MB
Storage type FLASH
Tested ambient temperature -40°C to 60°C
Suggested price $149.00
Powering
Details
Number of DC inputs 3 (DC jack, PoE-IN, Automotive)
DC jack input Voltage 9-30 V
Automotive input Voltage 9-30 V
Max power consumption 8 W
Cooling type Passive
PoE in Passive PoE
PoE in input Voltage 9-30 V
Wireless specifications
Details
Wireless 2.4 GHz Max data rate 300 Mbit/s
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n
Antenna gain dBi for 2.4 GHz 2
Wireless 2.4 GHz chip model QCA9531
Wireless 2.4 GHz generation Wi-Fi 4
Ethernet
Details
10/100 Ethernet ports 1
Peripherals
Details
Number of SIM slots 1 Modem (Mini SIM)
MiniPCI-e slots 1
Other
Details
PCB temperature monitor Yes
Voltage Monitor Yes
Certification & Approvals
Details
Certification CE, FCC, IC, EAC, ROHS
IP 54
Wireless specifications
2.4 GHz Transmit (dBm) Receive Sensitivity
1MBit/s 22 -96
11MBit/s 22 -89
6MBit/s 20 -93
54MBit/s 18 -74
MCS0 20 -93
MCS7 16 -71
Included parts
PoE injector
24V 0.8A power adapter
wAP desktop stand
Hose clamp 1
K-52 fastening set
