We all know the struggle of managing so
many devices with different interfaces and communication protocols.. You keep
adding new solutions to your setup to keep up, but the older devices are
still too good to let them go. How do you integrate all of them in a single
system that will serve you right? Easy – you “tie” them together by using the
KNOT!

It doesn’t matter whether you have devices that are no longer in
production, devices that came out this year, or even some custom solutions by
your technician – the KNOT can handle them all!

KNOT LR8 kit is an out-of-the-box IoT Gateway solution for LoRa®
technology. It uses Narrow Band and CAT-M technology. Because of the low
cost, low bandwidth cellular connection, it is supported by countless mobile
operators around the globe. This kit contains a pre-installed UDP packet
forwarder to any public or private LoRa® servers. With the support of 8
different channels, Listen Before Talk (LBT) and spectral scan features this
product will astound you with its enticing price point.

It could be used as a backup connection for the Ethernet or as a management
channel for your network. NB/CAT-M monthly plan is much cheaper than LTE. Why
spend extra money on bandwidth you don’t need? For example, you can manage a
KNOT-powered vending machine with temperature and moisture sensors with only
a few megabytes per day!

KNOT features so many protocol support and connectivity options: 2.4 GHz
wireless, Bluetooth, LoRa®, 2x 100 Mbps Ethernet ports with PoE-in and
PoE-out, Micro-USB. Maximum convenience at the lowest cost!

With the Bluetooth interface, you can use the KNOT for asset tracking and
telemetry based on Bluetooth advertisement packets. KNOT supports any BLE tag
that sends advertisement data. iBeacon, Eddystone or any other format. It has
powerful filters for forwarding only relevant packets and ignoring
others.

This kit can even help you in the most unusual situations. Remember the
part about onboard GPIOs? Those pins can be used to read all kinds of analog
sensors, interact with a single-board computer or other custom electronics –
hobbyist kits, D.I.Y. robotics… It’s like getting the whole Swiss Army
instead of a Swiss Army knife!

KNOT is a great tool for most outdoor cabinet IoT applications as well. It
comes with a DIN rail mount that allows easy integration with all kinds of
setups: from agriculture and asset tracking to cold chain monitoring,
industrial manufacturing, and so on.

Bring flexible low-cost connectivity to the most remote or tricky areas
with the MikroTik KNOT!

  Send purchase questions
 Specifications
 Support & Downloads
 Gallery
 Test results
Specifications
Details
Product code RB924iR-2nD-BT5&BG77&R11e-LR8
Architecture MIPSBE
CPU QCA9531
CPU core count 1
CPU nominal frequency 650 MHz
Switch chip model QCA9531
RouterOS license 4
Operating System RouterOS
Size of RAM 64 MB
Storage size 128 MB
Storage type NAND
MTBF Approximately 200’000 hours at 25C
Tested ambient temperature -40°C to 70°C
Suggested price $199.00
Powering
Details
MicroUSB input Voltage 5 V
Number of DC inputs 3 (DC jack, PoE-IN, MicroUSB)
DC jack input Voltage 12-57 V
Max power consumption 23 W
Max power consumption without attachments 5 W
Cooling type Passive
PoE in 802.3af/at
PoE in input Voltage 18-57 V
PoE-out
Details
PoE-out ports Ether2
PoE out 802.3af/at
Max out per port output (input 18-30 V) 650 mA
Max out per port output (input 30-57 V) 450 mA
Wireless specifications
Details
Wireless 2.4 GHz Max data rate 300 Mbit/s
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n
Antenna gain dBi for 2.4 GHz 1.5
Wireless 2.4 GHz chip model QCA9531
Wireless 2.4 GHz generation Wi-Fi 4
Ethernet
Details
10/100 Ethernet ports 2
Peripherals
Details
Number of SIM slots 1 Modem (Nano SIM)
MiniPCI-e slots 1
Serial console port RS485
Number of USB ports 1
USB slot type microUSB type AB
Max USB current (A) 1
Other
Details
PCB temperature monitor Yes
Voltage Monitor Yes
Bluetooth version 5.2
Bluetooth RF connector type uUFL
Certification & Approvals
Details
Certification CE, EAC, ROHS
IP 20
Wireless specifications
2.4 GHz Transmit (dBm) Receive Sensitivity
1MBit/s 22 -96
11MBit/s 22 -89
6MBit/s 20 -93
54MBit/s 18 -74
MCS0 20 -93
MCS7 16 -71
Included parts

24V 1.2A power adapter

K-47 wall mount set

DIN rail mount set

USB OTG cable

The device has an operating system preinstalled and licensed. No separate
purchase is necessary and the product is ready to use. The device includes
free software updates for the life of the product or a minimum of 5 years
starting from date of purchase..
